M-20F 30W 4-inch full frequency column speaker

01

Product category

M-20F 30W 4-inch full frequency column speaker

Features:

  • 4-inch indoor column
  • RMS power 30W
  • With 2 pieces full frequency loudspeaker

03

DATA INFORMATION

ITEM M-20F M-30F M-40F M-60F
RMS POWER 30W 40W 60W 90W
VOLTAGE INPUT 100V
SENSITIVITY 91dB±3dB
FQ RESPONSE 85hz-18Khz
LOUDSPEAKER 4“(Φ103mm×2)20mm cone 4“(Φ103mm×3)20mm cone 4“(Φ103mm×4)20mm cone 4“(Φ103mm×6)20mm cone
OUTSIDE SIZE 150×100×335mm 150×100×460mm 120×158×585mm 120×158×830mm
INNER BOX SIZE 168×118×380mm 168×118×500mm 168×118×630mm
MATERIAL Aluminum Alloy
COLOR WHITE
N.W. 1.5kg 2.5kg 3.5kg 4.5kg



04

PRODUCT DETAILS

05

installation drawings

How to install

  • Installation schematic:

  • Dimensions

  • Circuit schematic:

  • Wiring instructions:

    The amplifier output COM needs to be connected to the black wire when wiring, and the amplifier 100V output is connected to the required corresponding wire.

06

Packing


inner box


carton

Packing list

ITEM SIZE(cm) PCS/CTN CBM (m3) N.W. (kg) G.W. (kg) 20GP(pcs) 40HQ(pcs)
M-20F 37.5*35.5*40.5 6 0.054 9.00 12.00 2886 7332
M-30F 37.5*35.5*52.5 6 0.07 15.00 18.00 2226 5052
M-40F 35.5*25.5*65.5 4 0.059 14.00 16.00 1760 4472
M-60F

Accessories:

Required

——Mounting bracket + matching screws

Matching

——
